ETON VIPER 90 |
|
|
|
ETON VIPER90CCThe Viper 90 Silver Series ATVs have arrived. The EPA-approved 4-stroke Viper 90 88.4cc engine allows additional performance and freedom from a youth ATV. The Viper 90 includes necessary equipment to comply with EPA emissions standards. Recommended for ages 5 and up. Retail $2699.00 Promo $1699.00 MADE IN TAIWAN |
|
ENGINE |
|
||
|
Type |
Four cycle air cooled |
||
|
Displacement |
88.4cc |
||
|
Bore / Stroke |
47mm x 51mm |
||
|
Compression Ratio / Pressure |
10.2:1 |
||
|
Power |
7HP |
||
|
TRANSMISSION |
|
||
|
Type |
Automatic (C.V.T. V-Belt) |
||
|
CHASSIS |
|
||
|
Overall Length |
1500mm / 59.0" |
||
|
Overall Width |
850mm / 33.5" |
||
|
Overall Height |
940mm / 37" |
||
|
Wheel Base |
1030mm / 46.6" |
||
|
Ground Clearance |
127mm / 5" |
||
|
Dry Weight |
115kg / 253.3lbs |
||
|
SUSPENSION |
|
||
|
Front |
Dual A-arm with Adjustable Shocks |
||
|
Rear |
Swing Arm Adjustable Shock |
||
|
BRAKES |
|
||
|
Front |
Dual Mechanical drum |
||
|
Rear |
Hydraulic Disc |
||
|
TIRES |
|
||
|
Front |
18/7-8 |
||
|
Rear |
18/9-8 |
||
|
Tire Pressure |
Front |
Min |
3.2psi / 0.23kg/cm2 |
|
Max |
4.0psi / 0.28kg/cm2 |
||
|
Rear |
Min |
3.2psi / 0.23kg/cm2 |
|
|
Max |
4.0psi / 0.28kg/cm2 |
||
|
FLUIDS |
|
||
|
Fuel |
Type |
Unleaded Gasoline 89 octane |
|
|
Volume |
4.5liters / 1.2gal |
||
|
Engine Oil |
Type |
SAE 20W-40 |
|
|
SPARK PLUG |
|
||
|
NGK |
BPR7HS |
||
|
Electrode Gap |
0.6-0.7mm / 0.023" |
||
|
SAFETY FEATURES |
|
||
|
Remote Control Stop/Start |
Optional Kit (Stop Only) |
||
|
Safety Tether Switch |
N/A |
||
|
Enclosed Foot Rest Area |
Standard equipment |
||
|
Enclosed Engine Compartment |
N/A |
||
|
Maximum Rider Weight |
70 kg / 154 lbs |
||
|
Minimum Rider Age |
12 years |
||
|
Available Colors |
Red, Black/Silver |
||
